CFS redefines industrial material handling with engineered sheet metal vertical storage racks designed for oversized glass panels up to 130"×96". Our vertical metal plate storage racks combine military-grade durability with precision engineering for facilities prioritizing safety and space optimization.
Critical Industrial Challenges Addressed
● A museum conservation client required:Secure storage for 11ft×8ft crated glass panels
● 5,500 lb capacity per shelf
● Vertical configuration within 15ft spaces
● Full compatibility with overhead crane systems
The CFS vertical metal storage rack system delivered through these innovations: Precision Engineering Specifications
| Feature | Specification | Industrial Benefit |
| Panel Capacity | 130"×96"×10" | Accommodates ISO-certified crates |
| Load Capacity | 5,500 lbs/shelf | Exceeds ANSI safety standards |
| Vertical Configuration | 10 roll-out drawers | 65% space savings vs horizontal racks |
| Structural Integrity | 7,275 lb steel frame | Seismic-resistant stability69 |
| Operational Clearance | 263" full extension | Full vacuum lifter/crane access |
Material Protection Technology
● 2° engineered tilt with EPDM cushioning (70 Shore hardness)
● Spring-loaded retention bars (220 lb tension control)
● Laser-aligned V-guide wheels on 50×50mm tracks6
● Anti-microbial PVC edge protectors for humidity control
Industrial-Grade Operation
● Dual-track bearing system (400+ daily cycles certified)
● Modular bolt-together design adapts to facility layouts9
● RFID-ready inventory slots with load capacity indicators
● OSHA-compliant safety stops at 85% extension
Space-Optimized Design
● Compact 15ft footprint maximizes vertical cube utilization
● Adjustable 100mm roller positions for mixed panel sizes13
● Dual-system configuration fits 40ft warehouse bays
Global Logistics Solutions
● Knock-down ships in standard 20ft containers (2 units/container)
● Protection packages:
Economy: Military-grade stretch wrap ($13/sqm)
● Premium: ABS crating for transoceanic transport5AR-assisted mobile app guides assembly
Why Manufacturers Choose CFS
1. Multi-Material Versatility Stores glass, metal plates, and composite panels6
a. Quick-change configurations between materials
2. Workflow Optimization 60% faster retrieval vs traditional racks
a. Simultaneous access to all 10 shelves
3. Lifecycle Value 100,000-cycle durability certification
a. 10-year structural warranty
Implementation Protocol
1. Anchor to 6" reinforced concrete using M20 bolts9
2. Maintain 18" clearance for crane operations
3. Conduct quarterly track lubrication
Industrial Applications
● Architectural glass production lines
● Aerospace composite storage facilities
● Museum artifact preservation systems
● Automotive sunroof manufacturing
Transform Material Handling Workflows
CFS sheet metal storage racks vertical systems deliver measurable ROI:
● 90% reduction in panel damage incidents6
● 55% faster production line feeding
● 40% warehouse space reallocation
Need a Custom Storage Solution?
Speak directly with our technical engineers. We offer free structural designs, heavy-duty catalog evaluations, and quick B2B price quotations.
Request a Quote Now →
